5735 Series
Telco Centronic Connector; Solder Type Plug
[ EMI / RFI Shield ]

Materials:
Contact: Phosphor Bronze
Contact Plating: Gold
Contact Underplating: Nickel
Shell: Steel; Nickel Plated
Insulation: PBT & 30% glass fiber reinforced thermo plastic: UL94V-O
Color: Blue, black

Electrical:
Contact Current Rating: 5 Amp
Contact resistance: 30 Miliohms Max.
Insulation Resistance: 1000 Megohms @ 500V DC
Dielectric Withstanding: 1000V AC min. rms
Operation Temperature: -55oC to +105oC

Ordering Part Number

5735[] -

 [][] - [] []

Series Number

 Number of Positions Insulator Color Contact Plating

5735M (Plug)

5735F (Socket)

 14, 24, 36, 50 Blank: Blue
BK: Black		 Blank: Gold Flash
F: 10u" Gold
E: 15u" Gold
D: 30u" Gold

5735M-50

5735F-50
